VR Prosodic Speech Analysis System

01

Measuring how someone speaks

Inside a VR exercise, the way someone talks carries information the task score does not capture.

If someone is working through a simulated procedure in VR, the system already knows whether they completed the steps. It knows nothing about how they sounded doing it. Speech carries that: pitch, loudness, tempo, where the pauses fall. I wanted to turn that into a number while the exercise is still running.

A fixed threshold does not work. If I say that anything above 180 Hz or 70 dB counts as elevated, the system ends up measuring the person instead of their state. A naturally loud speaker crosses that line while calm. A quiet one never crosses it at all, even under real pressure. Any absolute acoustic threshold is a statement about voices in general, and what I wanted to detect was a change in one voice.

• Hardware One Windows PC, Meta Quest 3 over Quest Link, audio from the Oculus virtual microphone at 16 kHz mono
• Interaction One controller button: hold to record, release to analyse
• Boundary No audio analysis reimplemented in C#. One implementation, in Python
• Latency Analysis returns while the exercise is still running
• Discipline Return nothing before returning a bad score

02

Two anchors instead of one threshold

Every speaker gets their own scale, with both ends measured from their own voice.

Before the exercise, each user records two short sentences. The first is spoken normally and becomes their baseline. The second is spoken with urgency and becomes their upperline. For each feature, the distance between those two recordings is that person’s own range.

Everything after that is measured as progress along that range: zero at the baseline, one at the upperline. A loud speaker and a quiet speaker who have each moved the same proportion of their own way toward urgency get the same score.

The detail I am most pleased with is that the gap is signed. Most people speak faster under urgency, so their articulation rate upperline sits above their baseline. Some speak more slowly and deliberately instead. The formula does not treat that as an error to correct. It keeps whichever direction that person actually showed. The gap is simply negative, and progress along it is computed the same way.

raw_progress = (
  current_number - baseline_number
) / gap

# Baseline'ın ters yönündeki değişim panik puanı üretmez.
score_progress = max(raw_progress, 0.0)

# Upperline'ı aşmak mümkündür. 1.25 sınırı, tek özelliğin
# bütün skoru aşırı şişirmesini engeller.
score_progress = min(score_progress, 1.25)

weighted_progress += score_progress * weight
used_weight += weight

Six features carry the score. Each has a weight and a minimum gap. The minimum gap is the smallest separation between a person’s two anchors that still counts as a real difference instead of noise.

Timing comes from Faster-Whisper’s word-level timestamps instead of energy based voice activity detection. Energy VAD cannot tell a pause from a quiet room, and a noisy headset microphone makes it worse. Word boundaries from the transcript are a much better basis for saying where speech actually stopped. Syllables are approximated by counting Turkish vowels. That is a documented approximation and not a real syllabifier, and it is good enough for comparing a speaker with themselves.

The system is deliberately built in two layers with an HTTP bridge between them.

Keeping every measurement in Python is what makes that split worth having. Praat, librosa and Faster-Whisper have no equivalent in C#. Porting a subset of them into the VR project would have created a second implementation of the measurement, and I would have had to keep the two in agreement.

03

Making the score refuse to lie

Most of the engineering here is in the paths that return nothing.

A number on a panel gets believed. That is a good reason to be careful about when one is produced at all. The gates below are the part of this system I would most want to be judged on.

The feature level gate is the one that matters most. If a person’s baseline and upperline recordings did not separate on a given feature, that feature carries no information about them. Maybe they spoke at the same pitch both times. Including it would add noise dressed as signal. So it is dropped, and the score is computed from the features that did separate, reweighted.

That can cascade. Drop enough features and there is not enough profile left to score anything. Below two surviving features, or 0.40 of combined weight, calibration is rejected outright and the user records the anchors again.

Recording quality is checked before any of that. Clipping at a peak of 0.99 or above, a peak below 0.02, or fewer than 20% voiced frames all raise a warning. There is a subtler one too. If the voice activity detector reports that 98% or more of the window is active speech, that is usually a noisy room being heard as continuous talking, and the timing features derived from it are not trustworthy.

if speech_window > 0:
  active_ratio = active_duration / speech_window

  if active_ratio >= 0.98:
      warnings.append(
          "Kayıdın neredeyse tamamı aktif konuşma olarak algılandı. "
          "Gürültü nedeniyle VAD/sessizlik tespiti güvenilir olmayabilir."
      )

There is one more check I like. The calibration phrase itself is verified: the transcript of what the person said is compared against the sentence they were asked to say. A baseline recorded while someone was talking to the person next to them should not silently become the reference every later score is measured against.

04

The finished system

Button to score, end to end, on one machine.

The engine runs without the headset attached. That is how I developed it and how it stays testable: a WAV file and a phrase are enough to exercise the whole measurement path. The VR layer only ever triggers a recording and displays what comes back.
